MBW R442 User Manual
Page 20
- 17 -
ITEM
PART NO.
DESCRIPTION
QTY
1.
06173
COVER, SPRINGBOX
1
2.
06237
O-RING, 4.33 ID X 0.103 DIA
1
3.
06327
BUSHING
1
4.
07154
RING, CLAMPING, LOWER
1
5.
09618
FITTING, PLUG PARKER 4HP50N
1
6.
11694
BELLOWS, 4 PLY
1
7.
16311
RING, CLAMPING, UPPER
1
8.
16330
O-RING, 2.72 ID X 0.139 DIAMETER
1
9.
18276
PLUG, OIL LEVEL
1
10.
18693
SPRING, COMPRESSION, OUTER
2
11.
18694
SPRING, COMPRESSION, MIDDLE
2
12.
18695
SPRING, COMPRESSION, INNER
2
13.
19585
KIT, SHOE, 11” CAST IRON, (Includes items #12, 23 & 24)
1
14.
20027
SPRING BOX GUARD
1
15.
20039
SPRING SEPARATOR
1
16.
20041
SLIDE BEARING, SPRING SEPARATOR
1
17.
20043
SLIDE BEARING, SPRING BOX
1
18.
20044
RETAINING RING
1
19.
20162
SPRING BOX, 442
1
20.
20336
KIT, RAM SHAFT (Includes items 19, 25 & 6 from page 18)
1
21.
F042005FSS
FSS, 1/4-20 x 5/8”
3
22.
F042006FWS
FLANGE LOCK SCREW, 1/4-20 x 3/4, ZP
4
23.
F042007FWS
FLANGE LOCK SCREW, 1/4-20 x 7/8, ZP
6
24.
F071418SCS
SOCKET HEAD SCREW, 7/16-14 x 2-1/4
6
25.
F07LW
LOCKWASHER, 7/16 ZP
6
26.
F0813ELN
NYLOC NUT, 1/2-13, ZP
1
F081318HCS
HHCS, 1/2-13 x 2-1/4 GR5 ZP (For serial number 4420569 and below)
1
F08LW
LOCKWASHER, 1/2 ZP (For serial number 4420569 and below)
1
KITS:
20177
KIT, SLIDE BEARING (Includes items 15, 16, 17 & slide bearing in gear box)
20173
SPRING BOX ASM. (INCLUDES ITEMS 1, 2,9, 10, 11, 12, 14 thru 20, 25 & 26)
