DTS surround encoder - Manual (Page 11)

10. Frame rate: If the audio track is intended to sync with video, be sure to
match its frame rate. If the video reference is drop frame , you MUST select
drop frame here.
If it is important to match the start of the audio track to some specific point in
the video, enter the
Start time here, in hours:minutes:seconds:frames
(hh:mm:ss:ff) format. The End time will be calculated automatically, based on
the length of the Input Files and the selected frame rate.
11. The Input Files section of the screen is where you select the individual
source file to be assigned to each encoded channel. (See the Special Case
following step 12.)
Click the cursor on the left-hand column (the L in this example) to open
a file selection window (shown below).
Browse for an input file for the L channel, then select it.
To select, double-click on the file in the list. Or highlight the
file and click
Open.
Installation and User Manual – DTS Pro Series Surround Encoder
9
