15
Command Summary (-cont-)
Command Keyboard
Shortcut
Parameter Range Description
DELAy E & C 250n - 10m
Set delay to parameter
specified.
Ctrl-E set 1 ns* Up
Ctrl-C set 1 ns* Down
Alt-E set 10 ns* Up
Alt-C set 10 ns* Down.
*Varies depending on range.
RISE Home & End
50n, 100n, 200n,
500n, 1µ, 2µ, 5µ,
10µ
Set rise time to parameter
specified.
Home increases rise time
End decreases rise time
FALL
Page Up & Page
Down
500n, 1µ, 2µ, 5µ,
10µ, 20µ, 50µ,
100µ, 200µ, 500µ,
1m
Set fall time to parameter
specified.
PageUP increases rise time
PageDown decreases rise
time
AMPLitude
Up & Down
Arrow
0 - 10
Set amplitude to parameter
specified.
UP Arrow increases amplitude
Down Arrow decreases
amplitude
ATTEnuation
Left & Right
Arrow
1, 2, 5, 10, 20, 50,
100, 200, 500, 1000
Set attenuation to parameter
specified.
Right Arrow increases
attenuation
Left Arrow decreases
attenuation
PULSe
FLat, TAil, PLus,
MInus, ON, OFf
Set pulse to flat top or tail
pulse, positive or negative
going* and pulse on or pulse
off.
*see also POLARITY and
TAIL.
POLArity PLus, MInus
Set pulse to positive or
negative going pulse*
*see also PULSE
TAIL ON, OFf
Set tail pulse on or off*
*see also PULSE
