Steele Products SP-GG1000E - Manual (Page 29)

Owner’s Manual
28
Parts List
Crankcase Cover System Assy.
C
APA Part No. Description Part. No
SP-GG1000E-C-01-JD DUCT COVER JD5000-A-01
SP-GG1000E-C-02-JD FLANGE BOLT (M8 X 35) JD5000-A-02
SP-GG1000E-C-03-JD OIL SCALE JF340-C-03B
SP-GG1000E-C-04-JD OIL SCALE SEAL JF340-C-02
SP-GG1000E-C-05-JD OIL SEAL( 35Ч 52Ч8) JF340-B-11
SP-GG1000E-C-06-JD FLANGE BOLT (M8X35) JF390-C-01
SP-GG1000E-C-07-JD CRANKCASE COVER JF340-C-04B
SP-GG1000E-C-08-JD SLIDER SHAFT JF340-C-06
SP-GG1000E-C-09-JD GOVERNOR GEAR JF340-C-07
SP-GG1000E-C-10-JD GOVERNOR GEAR WASHER (6 mm) JF340-C-05
SP-GG1000E-C-11-JD SLIDER WASHER (6 mm) JF340-C-08
SP-GG1000E-C-12-JD GOVERNOR SLIDER JF340-C-09
SP-GG1000E-C-13-JD BALL BEARING (6202) JF340-B-13
SP-GG1000E-C-14-JD BALL BEARING (6207) JF340-B-04
SP-GG1000E-C-15-JD CRANKCASE COVER PAD JF340-C-10
SP-GG1000E-C-16-JD DOWEL PIN (8X 12) JF240-C-11
