FITTING REQUIREMENTS
REQUIRED TOOLS FOR FITMENT OF PRODUCT:
Basic tool kit
Non acidic silicon
HAVE AVAILABLE THESE SAFETY ITEMS WHEN FITTING PRODUCT
:
Protective eyewear
Hearing protection
NOTE: ‘WARNING’ notes in the fitting procedure relate to OHS situations, where to avoid a
potentially hazardous situation it is suggested that protective safety gear be worn or a safe work
procedure be employed. If these notes and warnings are not heeded, injury may result.
WHERE USED
PART No
QTY
DESCRIPTION
6562518L
1
Side rail assembly left hand side
6562518R
1
Side rail assembly right hand side
6151009
6
U-Bolt 140 x 85 x 16mm
6151137
12
Nut M16 hex head
4581051
12
Washer flat M16
SIDE STEPS TO CHASSIS
RAILS
4581052
12
Washer spring M16
3193758L
1
Step checker plate Dakar side step
3193758R
1
Step checker plate Dakar side step
6151200
16
Bolt M6 x25mm coach
4581084
16
Washer M6 flat panel
ALUMINIUM STEPS TO SIDE
RAILS
6151128
16
Nut M6 flange
271BLK
4
Side rail rubber plug
MISCELLANEOUS
215637
2
ARB logo sticker
Last Rev Date: 25/11/2008
Page 2 of 4
Fitting instructions# 3783206
