Assembly sequence for winch bumper – ARB 3952010 User Manual
Page 3
22/06/06
Page 3 of 9
3782946
ASSEMBLY SEQUENCE FOR WINCH BUMPER.
1.
Position the lower buffer on the winch bumper and
assemble using the M6 flange nuts. (do not over
tighten)
2.
Insert the side buffers through the holes and fix
using the M6 flange nuts. (Do not over tighten)
3.
Push the top chrome tube through the hole in the
buffer and fasten using the M12 x 40mm bolts,
washers and spring washers.
