WINCH BULL BARS TO SUIT
HOLDEN 2WD & 4WD RODEO – ALL MODELS
Part No 3448040 – Deluxe Bar
WARNING
THIS BULL BAR MUST NOT BE FITTED TO AIRBAG EQUIPPED VEHICLES.
FITMENT TO AIRBAG EQUIPPED VEHICLES MAY INTERFERE WITH THE
PROPER OPERATION OF THE AIRBAGS AND MAY RESULT IN SERIOUS
INJURY.
TAKE NOTE OF THE FOLLOWING:
• THIS PRODUCT MUST BE INSTALLED EXACTLY AS PER THESE
INSTRUCTIONS USING ONLY THE HARDWARE SUPPLIED.
• IN THE EVENT OF DAMAGE TO ANY BULL BAR COMPONENT, CONTACT
YOUR NEAREST AUTHORISED ARB STOCKIST. REPAIRS OR
MODIFICATIONS TO THE IMPACT ABSORPTION SYSTEM MUST NOT BE
ATTEMPED.
• DO NOT USE THIS PRODUCT FOR ANY VEHICLE MAKE OR MODEL,
OTHER THAN THOSE SPECIFIED BY ARB.
• DO NOT REMOVE LABELS FROM THIS BULL BAR.
• THIS PRODUCT OR IT’S FIXING MUST NOT BE MODIFIED IN ANY WAY.
TOOLS REQUIRED –
Standard mechanical tool box inc. 4mm Allen Key.
Winch fitment will require a 1/2” drill bit & drill
PROCEDURE –
Note: If fitting winch bar and winch read winch fitment section before
proceeding.
1. Remove the bumper bar and tow hook.
2. Remove indicator lamps from bumper bar & refit lamps into bull bar using original
screws.
3. Lift bull bar onto the vehicle’s chassis & bolt the outer bull bar brackets to the
chassis using the original 12mm bolts – finger tighten only.
