9/10/01 Page 8 of 9 3782892
16. 23. With the aid of another person place the bar on
the mounts. Line the bar to the vehicle with a10
- 15mm gap between vehicle and bar. Fasten
using six M12 x 40mm bolts six ½’’ washers
and six spring washers. Tighten all bolts firmly.
17. 24. Cut the excess wires from under the vehicle so
they don’t protrude past the chassis rail.
18. 25. Place the rubber caps over the cut ends of the
wires.
