If you have any queries regarding the installation of this product please contact the distributor from whom it was purchased, or alternatively the ARB office in your state.
Head Office – ARB corporation Ltd VIC: 42-44 Garden Street, Kilsyth, Victoria, 3137 Tel: (03) 9761 6622 Fax: (03) 9761 6807
WA:(08) 9244 3553 NSW: (02) 9821 3633 ACT: (02) 6280 7475 SA: (08) 8244 5001 QLD: (07) 3872 3872 NT: (08) 8947 2262 TAS: (03) 6331 4190
ARB WINCH BULL BAR TO SUIT
MITSUBISHI CHALLENGER
No 3435010
WARNING
FOR VEHICLES EQUIPPED WITH SRS AIRBAG
WHEN INSTALLED IN ACCORDANCE WITH THESE INSTRUCTIONS, THE FRONT
PROTECTION BAR DOES NOT AFFECT OPERATION OF THE SRS AIRBAG.
TAKE NOTE OF THE FOLLOWING:
• THIS PRODUCT MUST BE INSTALLED EXACTLY AS PER THESE INSTRUCTIONS USING ONLY THE
HARDWARE SUPPLIED.
• DO NOT USE THIS PRODUCT FOR ANY VEHICLE MAKE OR MODEL, OTHER THAN THOSE SPECIFIED
BY ARB.
• DO NOT REMOVE LABELS FROM THIS BULL BAR.
• THIS PRODUCT OR ITS FIXING MUST NOT BE MODIFIED IN ANY WAY.
BULL BAR FITTING KIT No 6171295
USE
PART No
QTY
DESCRIPTION
IMPACT ABSORBERS
3751726L&R
PAIR IMPACT ABSORBER
6151045
8
M10 X 25mm BOLT
4581048
8
M10 SPRING WASHER
4581040
12
M10 FLAT WASHER
6151021
2
M8 X 20mm BOLT
4581044
2
M8 FLAT WASHER
6151132
2
M8 FLANGE NUT
AIR DEFLECTOR
6521027
1
AIR DELFECTOR
6151021
4
M8 X 20mm BOLT
6151132
4
M8 FLANGE NUT
4581044
4
M8 FLAT WASHER
IMPACT ABSORBER TO
6151230
2
7/16” X 4” BOLT
VEHICLE CHASSIS
4581041
4
7/16” FLAT WASHER
4581042
2
7/16” SPRING WASHER
6151124
2
7/16” NUT
CONTROL BOX BRKT &
3751619
1
BRKT CONTROL BOX
NUMBER PLATE
6151017
4
M6 X 16mm BOLT
6151046
4
M6 FLAT WASHER
6151128
4
M6 FLANGE NUT
180302
4
CABLE TIES
3500170
1
BUFFER KIT (LH & RH WITH
FLANGE NUTS)
