3 Installing the Air Locker
24
3.14 Reinstalling the Differential Assembly
c Reassemble the differential assembly according to your vehicle
manufacturer’s service manual using gasket sealant where
necessary.
NOTE : Be careful not to damage the sintered bushings in the
ends of the Air Locker when installing axle stubs. The
fit should be snug, and light tapping may be required
to fully insert the stubs into the splines. In some
cases a small chamfer may need to be ground onto
the axle stubs as a lead-in for insertion into the
bushings.
c Install the differential assembly into the vehicle.
c Insert both CV axles completely into the housing and gently tap
them inward until the retaining clips have seated.
NOTE : Be careful not to damage oil seals with the axles.
c Reassemble brakes and wheels according to your vehicle’s service
manual.
c Reconnect the drive shaft flange.
