5 Mounting & Connecting the Electrical System
31
5.2
Wiring the Actuator System
5.2.1
Connection to an ARB AIR COMPRESSOR
When wiring the Air Locker actuator switch(es) and solenoid(s) to an
ARB Air Compressor, all connections can easily be set up directly from
the supplied wiring loom. (Fig. 23.)
NOTE : 180405 & 180409 model looms shown for reference
only. Refer to your ARB Air Compressor Installation
Guide for details on configuring your installation.
Figure 23.
180405
180409
