Page 44: Itemized parts list

8 Parts List
42
8.2
Itemized Parts List
(See exploded diagram figure 25.)
AIR LOCKER MODEL No. :
RD12
ITEM # QTY
DESCRIPTION
PART #
01
1
FLANGE CAP
020801
02
1
CLUTCH GEAR
050202
03
1
DIFFERENTIAL CASE
011007
04
4
PISTON SPRING
150101
05
2
CROSS SHAFT RETAINING PIN
120303
06
1
LONG CROSS SHAFT
060205
07
1
SHORT CROSS SHAFT
060402
08
1
PISTON (Polyamide)
040202
09
1
BONDED SEAL
160705
10
1
CYLINDER CAP
030213
11
2
SEAL HOUSING O-RING
160205
12
6
CYLINDER CAP RETAINING BOLT
200205
13
6
TAB WASHER – 8mm
150401
14
1
TAPERED ROLLER BEARING
160104
15
1
SHIM KIT
SHK002
16
1
SEAL HOUSING ASSEMBLY
080501
17
1
SPLINED SIDE GEAR
130401
18
1
SPIDER BLOCK
070301
19
4
PINION GEAR
140201
20
3
PINION THRUST WASHER
151102
21
1
SIDE GEAR
130201
22
2
SIDE GEAR THRUST WASHER
151002
*
1
‘C’ CLIP KIT
CCK004
*
1
BULKHEAD KIT, O-RING TYPE, 3.5-5mm
170105
*
1
PUSH-IN FITTING,5mm (R1 5 1/8”)
170201
*
1
AIR LINE (5mm DIA X 6m LONG)
170301
*
1
NIPPLE, 1/8” BSP,MALE TO MALE
170501
*
1
SOLENOID VALVE
180103
*
1
ACTUATOR SWITCH
180209
*
1
SWITCH COVER (REAR)
180211
*
10
CABLE TIE
180301
*
1
WARNING LABEL
210101
*
1
BUMPER STICKER
210102
*
1
OPERATING & SERVICE MANUAL
210200
*
1
INSTALLATION GUIDE
210212
* Not illustrated in exploded view.
