7 Parts List
42
7.2
Itemized Parts List
(See exploded diagram figure 30.)
AIR LOCKER MODEL No. :
RD84
ITEM # QTY
DESCRIPTION
PART #
01
1
SPLINED SIDE GEAR
131405R
02
1
SPIDER BLOCK
070902
03
1
LONG CROSS SHAFT
060204
04
1
SIDE GEAR
131305R
05
2
SIDE GEAR THRUST WASHER
151010
06
2
COUNTERSUNK SCREW
200213
07
2
CROSS SHAFT RETAINING PIN
120601
08
2
SEAL HOUSING O-RING
160235
09
1
SEAL HOUSING ASSEMBLY (Ø73.4 [2.9”])
081801
*
1
SEAL HOUSING ASSEMBLY (Ø77.8 [3.1”])
081802
10
1
SHIM KIT (Ø73.2 [2.9”])
SHK003
*
1
SHIM KIT (Ø77.7 [3.1”])
SHK002
11
2
TAPERED ROLLER BEARING
160114
12
1
FLANGE CAP ASSEMBLY
028403
13
1
BONDED SEAL
160702
14
1
CLUTCH GEAR
050801
15
8
RETURN SPRING
150107
16
1
SHORT CROSS SHAFT
060403
17
3
PINION GEAR
140701R
18
3
PINION THRUST WASHER
151110
19
1
DIFFERENTIAL CASE
013003
*
1
C-CLIP KIT
CCK005
*
1
BULKHEAD KIT,O-RING TYPE,3.5-5mm
170105
*
1
PUSH-IN FITTING,5mm (R1 5 1/8”)
170201
*
1
AIR LINE (5mm DIA X 6m LONG)
170301
*
1
NIPPLE, 1/8” BSP,MALE TO MALE
170501
*
1
SOLENOID VALVE
180103
*
1
ACTUATOR SWITCH
180209
*
1
SWITCH COVER (REAR)
180211
*
10
CABLE TIE
180301
*
1
WARNING LABEL
210101
*
1
BUMPER STICKER
210102
*
1
OPERATION & SERVICE MANUAL
210200
*
1
INSTALLATION GUIDE
210284
* Not illustrated in exploded view.
