Page 44: Itemized parts list
8 Parts List
42
8.2
Itemized Parts List
(See exploded diagram figure 25.)
Air Locker MODEL No. :
RD115
ITEM # QTY
DESCRIPTION
PART #
01
1
FLANGE CAP
022501
02
1
CLUTCH GEAR
050401
03
1
DIFFERENTIAL CASE
012401
04
4
PISTON SPRING
150101
05
3
CROSS SHAFT RETAINING PIN
120301
06
1
LONG CROSS SHAFT
060703
07
2
SHORT CROSS SHAFT
060802
08
1
PISTON (Polyamide)
040501
09
1
BONDED SEAL
160703
10
1
CYLINDER CAP
031203
11
2
SEAL HOUSING O-RING
160220
12
8
CYLINDER CAP RETAINING BOLT
200206
13
8
TAB WASHER – 8mm
150401
14
1
TAPERED ROLLER BEARING
160113
15
1
SEAL HOUSING
080703
16
1
SHIM KIT
SHK006
17
1
SPLINED SIDE GEAR
130805
18
4
PINION THRUST WASHER
151104
19
4
PINION GEAR
140401
20
1
SPIDER BLOCK
070401
21
1
SIDE GEAR
130705
22
2
SIDE GEAR THRUST WASHER
151004
*
1
BULKHEAD KIT,O-RING TYPE,3.5-5mm
170105
*
1
PUSH-IN FITTING,5mm (R1 5 1/8”)
170201
*
1
AIR LINE (5mm DIA X 6m LONG)
170301
*
1
NIPPLE, 1/8” BSP,MALE TO MALE
170501
*
1
SOLENOID VALVE
180103
*
1
ACTUATOR SWITCH
180209
*
1
SWITCH COVER (FRONT)
180210
*
1
SWITCH COVER (REAR)
180211
*
10
CABLE TIE
180301
*
1
WARNING LABEL
210101
*
1
BUMPER STICKER
210102
*
1
OPERATING & SERVICE MANUAL
210200
*
1
INSTALLATION GUIDE
2102115
* Not illustrated in exploded view.
