6 Testing & Final Assembly
30
! Turn the compressor (or alternate air source) on to charge the air
supply up to its maximum pressure.
! Rotate one wheel by hand.
! The wheel should rotate freely and the opposite wheel should be
turning in the opposite direction without any resistance or
mechanical noise from within the differential.
! Turn the Air Locker switch to the ‘ON’ position. The illuminated
symbol on the switch cover should light up.
! Rotate the same wheel again.
! Both wheels should rotate together.
! Turn the switch off again.
! Rotate the same wheel.
! The wheels should again rotate in opposite directions.
6.3 Filling the Differential
NOTE : Consult the ARB Air Locker Operating & Service
Manual for recommendations on differential lubricant
specifications.
! Refill the differential until level with the filler hole.
! Rotate the differential center 2 full turns.
! Check the oil level and add oil if necessary.
! Apply thread sealant to filler plug before inserting.
! Replace the filler plug.
! Clean the differential housing of any oil or grease that may collect
dirt or other abrasive particles.
