Section 2 - Pre-Operation and Inspection
2-4 31200169
OX0582
4-LEFT 4-LEFT
QU E
B H R
R O T U
91143280
(S/N 0160027138
thru
S/N 0160035941) 91143284
9114-3283
NO RIDERS PERMITTED ON HANDLER. OPERATOR ONLY IN MACHINE WHILE RUNNING. RIDERS COULD FALL OFF MACHINE CAUSING SERIOUS INJURY OR DEATH. 9114-3280
EXHAUST SYSTEMS CAN BE HOT. KEEP AWAY FROM EXHAUST SYSTEM WHEN HOT. HOT EXHAUST COMPONENTS CAN CAUSE SEVERE BURNS.
91163130
ADD
CHECK OIL LEVEL WITH HANDLER LEVEL AND ALL CYLINDERS RETRACTED. 1 GALLON BETWEEN ADD AND FULL MARKS
FULL
HYDRAULIC OIL LEVEL
9116-3130
91143282
9114-3282
STAY CLEAR OF PINCH POINT AREA ANYTIME ENGINE IS RUNNING. BEING IN PINCH POINT AREA COULD CAUSE SERIOUS INJURY OR DEATH.
91143281
9114-3281
STAY CLEAR OF MOVING PARTS WHILE ENGINE IS RUNNING. MOVING PARTS CAN CAUSE SERIOUS INJURY.
91143280
(BEFORE
S/N 0160027138)
9114-3280
EXHAUST SYSTEMS CAN BE HOT. KEEP AWAY FROM EXHAUST SYSTEM WHEN HOT. HOT EXHAUST COMPONENTS CAN CAUSE SEVERE BURNS.
91143285
(BEFORE
S/N 0160035983)
9114-3285
WHEN JUMP STARTING MATERIAL HANDLER * NEVER ALLOW VEHICLES TO TOUCH * CONNECT THE POSITIVE (+) JUMPER CABLE TO POSITIVE (+) POST OF DISCHARGED BATTERY * CONNECT OPPOSITE END OF POSITIVE (+) JUMPER CABLE TO POSITIVE (+) POST OF BOOSTER BATTERY * CONNECT THE NEGATIVE (-) JUMPER CABLE TO NEGATIVE (-) POST ON BOOSTER BATTERY * CONNECT OPPOSITE END OF NEGATIVE (-) JUMPER CABLE TO GROUND POINT ON MACHINE AWAY FROM DISCHARGED BATTERY * FOLLOW STANDARD STARTING PROCEDURES * REMOVE CABLES IN REVERSE ORDER AFTER MACHINE HAS STARTED
JUMP STARTING INSTRUCTIONS
80603026
8060-3026
COOLING SYSTEM IS PRESSURIZED. REMOVE CAP SLOWLY. HOT FLUID CAN CAUSE BURNS.
91083492
(BEFORE
S/N 0160035983)
1706300
(S/N 0160035983
& AFTER)
91143282
9114-3282
STAY CLEAR OF PINCH POINT AREA ANYTIME ENGINE IS RUNNING. BEING IN PINCH POINT AREA COULD CAUSE SERIOUS INJURY OR DEATH.
5-T 5-TOP OP
91143288
(BEFORE
S/N 0160035983)
R
For Mobil Product Information, Call 1-800-662-4525.
HYDRAULIC SYSTEM FILL WITH TRACTOR HYDRAULIC FLUID
or equivalent. 9114-3288
Genuine Parts
91143286
9114-3286
DIESEL FUEL IS FLAMMABLE EXTINGUISH ALL OPEN FLAME AND SMOKING MATERIALS WHEN REFUELING INJURY OR DEATH COULD RESULT FROM FIRE.
91143162
TEST PORTS
IMPLEMENT PRESSURE
IMPLEMENT PRESSURE
9114-3162
91343016
9134-3016
TURBOCHARGER DAMAGE CAN RESULT FROM QUICK START-UP & SHUTDOWN. FOR LONGER TURBOCHARGER LIFE AND TO MINIMIZE TURBOCHARGER DAMAGE, IDLE ENGINE AT LEAST 3-5 MINUTES AFTER START-UP AND BEFORE SHUTDOWN.
91143120
MACHINE MUST BE
IN NEUTRAL AND
PARK BRAKE ON TO START
ACC OFF RUN
START
91083314
(BEFORE
S/N 0160035983)
TRACTION LOCK SWITCH
9108-3314
DO NOT ENGAGE WHEN WHEELS ARE
IN MOTION OR ON IMPROVED SURFACES. MACHINE MUST BE IN 4
WHEEL DRIVE.
SWITCH LOCATED ON FLOOR. SWITCH
HYDRAULICALLY LOCKS FRONT AND REAR WHEELS TOGETHER FOR
INCREASED TRACTION.
ON
OFF
ALT 4X2 OFF 0 0 0 0 0 0
QUARTZ DRIVE 4X4 ON
240
100
F
E
80
0 16
10
TEMP
FUEL OIL
VOLTS
- +
9103-3089
9116-3184
9103-3089
91033089 91163028
LIFT TO SHIFT
91323030
9132-3030
NEVER OPERATE MACHINE WITHOUT CONSULTING PROPER CAPACITY CHART FOR THE CARRIAGE/FORK COMBINATION BEING USED.
91143182
9114-3182
VIEW OF CAB DASH
CAPACITY
CHARTS
