BASIC OPERATION
BASIC
OPERATION This dispensing equipment is designed for ease of use. The following steps
represent the method by which a formula is to be dispensed:
1. Determine the formula of the color selected by the customer.
2. Refer to the formula book and select the proper base paint.
3. Remove the lid on the base paint.
4. Pull out the appropriate shelf and place the can of base paint on the shelf.
5. Press the indexing lever down and rotate the turntable to the position
indicated by the formula book.
6. Turn the pump gauge to center the indicator pointer.
7. Lift the pump handle up until the indicator is opposite the notch on the
gauge.
8. Turn the gauge into the notch that represents the desired amount of colo-
rant per the formula book.
9. After the pump handle has been in this position for about three (3) sec-
onds, slowly pull the valve lever down and hold in that position with the
left hand.
10. While holding the valve down with the left hand, turn the gauge to the
center of the indicator and slowly push the pump handle down all of the
way to the bottom of the stroke. This will dispense a metered amount of
colorant into the base paint. (Repeat this step as may be required by the
formula book.)
11. Referring to the formula book, Pull down the indexing lever and rotate
the turntable to the next position indicated and repeat these steps for
each of the colorants in the formula.
12. At this point in the process, the can of base paint has been tinted.
Remove the can, press the lid back on and mix appropriately.
