Hale 11HP Super Chief - Manual (Page 6)

Page 6
30" x 30" x 23" (76cm x 76cm x 58.5cm)
In box fully assembled:
131 lbs (59.4 Kilograms)
118 lbs (53.5 Kilograms)
Pump: 86 lbs (39.0 Kilograms)
Float: 32 lbs (14.5 Kilograms)
Gas tank 3 Quarts / 2.8 Liters
Oil 1.5 Quarts / 1.4 Liters
Briggs & Stratton Intek Series
11.5HP, 3600 RPM @ no load
21 cubic inch / 344 cc
Single cylinder
Overhead Valve (OHV) Design
Advanced Anti-Vibration System (AVS
TM )
.5" / 1.2cm cast aluminum alloy. Built-in suction guard and skids
2.5" NST male / ISO 228/1-G21/2A Parallel Pipe
3" / 8mm hose diameter recommended for full output. 2.5"/6.5mm
minimum.
High density polyethylene shell filled with closed-cell polyurethane
foam.
Chief - 1 Discharge (See Page 7 for Pump Curve)
Max head pressure 50 psi (3.4 Bars)
Max. head 115 feet (35 meters)
Max. output 425 GPM (1609 LPM) @ 7 psi
Above 40 o
F
/ 4 O C
SAE 30
Below 40 o
F
/ 4 o
C
SAE 5W-30, 10W-30
Lead-free, minimum of 85 Octane
Note: Use detergent oil classified for service, SC, SC, SE, SF, SG.
U
NIT
S
IZE
Shipping Weight
Net Weight
Engine Capacities
Engine Specifications
Pump Body
Discharge
Float
Pump Performance
Lubricant
and
Fuel
Chief 11.5HP Pump Specifications
