Bush Hog RTC48 - Manual

SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE Page 41
Bush hog ® Tough FeaTures
Tough heavy Duty gearbox
Tough slip Clutch Is standard
Tough adjustable skid shoes
Tough Formed Tailgate
Tough Double strap hitch
Bush hog
®
Tough
subcompact Tillers
For Tractors up to 24 hP
MoDel rTC40 rTC48
Total Width 43 inches 53 inches
Tilling Width 39 inches 48 inches
Number of Blades 16 20
Minimum Tractor hP 15 PTO 15 PTO
Type hitch ASAE Cat. I / QH ASAE Cat. I / QH
offset 4 inches Offset to the Right Center Mount
Number of Flanges 4 5
rotor speed 253 RPM/540 PTO 253 RPM/540 PTO
Type of Blades C-type C-type
Power to rotor Transmission Chain Drive (#60) Chain Drive (#60)
Depth of Cut 6 inches 6 inches
Driveline Slip Clutch Standard Slip Clutch Standard
approximate Weight 308 lbs 335 lbs
Warranty 1 year limited warranty
FeaTures • Available in major tractor colors
Model rTC48
