8
English
Top and Front Panels
1 POWER slider – selects sound source
for MP3-CD, CD, RADIO,TAPE/ OFF , and the
power on/ off switch
2 LIFT TO OPEN –
opens/ closes the CD door
3 Display – shows the status of the set
4 Cassette recorder keys:
PAUSE ; – pauses recording or playback
STOP•OPEN 9/ –
stops the tape; opens the cassette door
SEARCH 5 or 6 –
fast rewinds/ winds the tape
PLAY 1 – starts playback
RECORD 0 – starts recording
5 BATT LOW – indicator lights up if
battery power is running low
6 PLAY•PAUSE 2; –
starts or pauses MP3-CD/ CD playback
7 STOP 9 – stops MP3-CD/ CD playback;
erases a MP3-CD/ CD program
8 TRACK•SEARCH ∞ , §
MP3-CD: skips or searches a passage/
track backwards or forward
RADIO: tunes to a radio station
(up, down)
9 FM•AM – selects FM/ AM waveband
10 TRACK +/–10 PRESET 3, 4
MP3-CD: fast skips to the next/ previous
10 MP3-CD/ CD tracks (if available)
RADIO: selects a preset station (up, down)
11 CD MODE•PROGRAM
MP3-CD: programs and reviews
programmed track numbers;
– plays tracks /discs/ program in
random order;
– repeats a track/disc/ program
RADIO: programs radio preset stations
12 DBB OFF / ON (Dynamic Bass Boost) –
enhances bass response
13 VOLUME – adjusts volume level
Back Panel
14 Telescopic antenna –
to improve FM reception
15 Battery door – open to insert
6 x 1.5V R14/UM2/ C-cell batteries
16 Voltage selector – (not all versions)
to match local power before connecting the
power cord by adjusting the selector
17 AC MAINS – inlet for power cord
Controls
