ENGLISH
C
4 Lubricate the trimmer teeth with one
drop of mineral oil every 6 months.
5 Close trimmer by pressing trimmer down.
Replacing the Razor Heads
◗ Replace the razor heads once a year for
optimal shaving results.
◗ Replace damaged or worn razor heads with
model HQ8 Philips Norelco razor heads only.
1 Turn razor OFF, remove the charging plug
from the outlet and power cord from the
razor.
C
2 Press the Razor Head Release Button to
open the Razor Head Assembly.
C
3 Pull the shaving unit off the razor.
C
4 Turn the lock counterclockwise to unlock
(1) and remove the retaining frame (2).
5 Remove the razor heads and place the
new razor heads in the shaving unit.
22
ENGLISH
C
Make sure that the two pointy edges of the head
fit exactly into the recesses.
6 Replace the frame and turn the lock
clockwise until it locks into place.
C
7 Insert the notch of the shaving unit into
the slot in the top of the razor (1) and
then close the shaving unit (2).
NOTE: If the shaving unit does not close smoothly,
make sure you inserted the shaving heads
properly and that the retaining frame is locked.
This razor has no other user-serviceable parts.
For assistance call 1-800-243-3050.
Storage
◗ Be sure razor is turned off. Remove cord from
outlet and razor before storing in a safe, dry
location where it will not be crushed, banged,
or subject to damage.
◗ Do not wrap power cord around razor when
storing.
◗ Store cord in a safe location where it will not
be cut or damaged.
◗ Do not place or store razor where it can fall
or be pulled into a tub or sink, water or other
liquid while plugged in.
C
◗ Put the Protective Cap on razor to protect
heads.
23
