Billion BiPAC SHDSL/SHDSL.bis (VPN) Firewall Bridge/ Router
Chapter 4: Configuration
134
Configuring L2TP VPN in the Branch Office
The IP address 69.1.121.30 is the Public IP address of the router located at head office. If you
registered the DDNS (please refer to the DDNS section of this manual), you can also use the
domain name instead of the IP address to reach the router.
Item Function Description
1
Connection
Name
BranchOffice Given a name of L2TP connection
Dial out Check the Dial out radio button
2 Server IP
Address (or
Hostname)
69.121.1.33
IP address of the head office router (in WAN
side)
Peer Network IP 192.168.1.0
3
Netmask 255.255.255.0
Head office network
Username username
4
Password 123456
Input username & password to authenticate
branch office network
5 Auth.Type Chap(Auto) Kept as a default value in most cases.
1
2
3
4
5
6
7
