16 EN
2
If necessary, rotate the USB connector on
the docking speaker, and then place your
Android-powered phone onto the dock.
3
Adjust the bumpers on both sides of the
connector to stabilize the phone.
4
Slide the connector to place your phone in
the middle of the docking speaker.
Tip
‡ If the micro USB connector is located at the top, and
your are using Android system of version 2.3 or above,
screen auto-rotation is available.
Use dock extension
If the USB connector on your phone is close
to the edge, the supplied dock extension can
balance the docked phone, as illustrated.
1
Adjust the slide knobs to make both
bumpers at the lowest position.
2
Place the dock extension onto the dock.
3
Dock your phone.
Charge Android-powered phone
When the docking speaker is connected to
power, the docked phone starts charging
automatically.
Tip
‡ This function is also available for non Android-powered
device that has a micro USB connector.
Dock extension
