Overview
Specifications
Part No.:
F1DC108C-US, F1DC116C-US
Enclosure:
Metal enclosure
Power:
12V DC, 6A power adapter, center-pin-positive
polarity
Daisy-Chain:
Maximum of 16 OmniView KVM Switches
No. of Servers Supported: 8 and 16 respectively for 8- and 16-port models
(256 servers max. via daisy-chaining)
Monitors Supported:
CRT and LCD (with VGA support)
Max. Resolution:
Up to 1280x1024 @ 65Hz
Keyboard Input:
PS/2 (miniDIN6), USB (Type A)
Mouse Input:
PS/2 (miniDIN6), USB (Type A)
Monitor Port:
VGA (HDDB15 female)
CPU Ports:
SCSI-50
Daisy-Chain Ports:
DB25 female
Flash-Upgrade Port:
RJ11
Operating Temp:
32° to 104° F (0~40° C)
Storage Temp:
-4° to 140° F (20~60° C)
Humidity:
0-80% RH, non-condensing
Warranty:
2 years
Dimensions:
26.1 x 17.6 x 1.74 in.
(673mm x 448mm x 44.1mm)
Weight:
(F1DC108C-US) 33.3 lbs. (15.1kg.)
(F1DC116C-US) 36.1 lbs. (16.4kg.)
Note: Specifications are subject to change without notice.
