Philips COLOR TV - Manual

T ABLE OF C ONTENTS
Getting Started
Warning/Precautions........................................1
Basic Television Hookups ...............................1
Basic Television and Remote Operation .......................2
How to Use the Onscreen Menu Controls ....................3
Setting Up Your Television for the First Time ..........3-4
• For details on product registration, warranty, and ser-
vice refer to the other literature (Owner’s Manual)
included with your TV information packet.
Please retain all these materials and keep them handy
for future reference.
WARNING: TO PREVENT FIRE OR SHOCK HAZ-
ARD DO NOT EXPOSE THIS UNIT TO RAIN OR
EXCESSIVE MOISTURE.
NOTE: This owner's manual is used with several
different television models. Not all features (and
drawings) discussed in this manual will necessar-
ily match those found with your television set.
This is normal and does not require you contact-
ing your dealer or requesting service.
3135 015 18351
Quick Use and Setup Guide
Color Television
TP2785C1
12 1 2
3
4 5 6 7
8
9
10
11
H
OOKING
U
P
Y
OUR
TV (B
ASIC
A
NTENNA
/C
ABLE
TV C
ONNECTIONS
)
75
Ω
IN OUT
1
75 Ω
L AUDIO R
MONITOR OUT AV1 AV2 VIDEO
S-VIDEO
2
Y our Cable TV input into
your home may be a
single (75 ohm) cable, or a
Converter Box installation.
In either case the connec-
tion to the TV is very easy.
Just put the threaded end
of the cable signal to the
TV's antenna plug and
screw it down tight.
C
ABLE
TV
C ABLE I NPUT /C ONVERTER
75 Ω
2
OR
OUT TO TV IN FROM ANT.
1
75 Ω L AUDIO R
MONITOR OUT AV1 AV2 VIDEO
S-VIDEO
T he basic Antenna, or
Cable TV, to VCR to
TV connection is shown to
the right. For more infor-
mation on other hookups
(possible when Cable
Converter/Descrambler
boxes are included) refer to
your accessory VCR and
Cable Converter Owner's
Manual for details.
TV
TO
VCR
B ASIC C ONNECTION
If your Cable TV signal
is a single round cable (75
ohm) then you're ready to con-
nect to the TV.
If you have a Cable
Converter Box:
Connect the Cable TV signal to
the Cable Signal IN(put) plug
on the Converter.
Connect the Cable TV cable to the
ANTENNA/CABLE plug on the TV.
If you have a Cable Converter Box:
Connect the OUT(put) plug from the
Converter to the 75
Ω
plug on the TV.
BEGIN
Connect your
Antenna or Cable TV signal
to the IN FROM ANT(enna)
plug on the VCR.
Connect the OUT TO
TV plug on the VCR to the
75
Ω
plug on the TV (connect-
ing cable supplied with the
VCR.)
BEGIN
Back of TV
Round Cable
75 Ω Ohm
Cable TV Converter
Box Connection
Cable TV Company
Remember:
Set the TV for the
type signal you've
just connected (see
the “Tuner” section
on page 3 of this
Set-Up Guide.)
To select only the
channel numbers on
your Cable system
see “Auto Program"
(page 4). If you use a
Cable Converter box,
set the TV to the
same channel as the
converter's CH 3/4
switch (on the rear of
the converter.)
S MART
H ELP
Cable TV Signal Input
Round Cable
75 Ω Supplied with VCR
Outdoor
VHF/UHF
Antenna
300 to 75 Ω
Ohm Adapter
Cable TV signal
Back of TV
Refer to the Owner's
Manual included with your
VCR for other possible con-
nections and TV/VCR operat-
ing details.
OR
NOTE: The connecting cable
for the Converter is supplied
from the Cable TV Company.
VCR
75
Ω
75 Ω L AUDIO R
MONITOR OUT AV1 AV2 VIDEO
S-VIDEO
2
1
A combination antenna
receives normal broad-
cast channels (VHF 2-13
and UHF 14-69). Your
connection is easy since
there is only one 75
Ω
(ohm) antenna plug on the
back of your TV - and
that’s where the antenna
goes.
A
NTENNA
C OMBINATION UHF/VHF Remember,
be sure to set the TV
for the type signal
you've connected
(see the “Tuner”
section on page 3 of
this Set-Up Guide.)
To set the TV to
select only the chan-
nel numbers in your
area see how to
“Program" or "Add"
channels in memory
on page 4 (Auto
Program section).
To order any option-
al accessory contact
your dealer or call
the toll-free accesso-
ry ordering number
(1-800-851-8885).
S MART
H ELP If your antenna has a
round cable (75 ohm) on the end,
then you're ready to connect it to
the TV.
If your antenna has flat twin-lead
wire (300 ohm), you first need to
attach the antenna wires to the
screws on a 300 to 75 ohm adapter.
Push the round end of the
adapter (or antenna) onto the
75
Ω
plug on the rear of the TV.
If the round end of the antenna
wire is threaded, screw it down
tight.
300 to 75 Ω
Adapter
Combination VHF/UHF
Antenna
(Outdoor or Indoor)
Twin Lead
Wire
Round Cable
75
Ω
Back of TV
BEGIN
OR
Note: For homes with separate UHF and VHF
antennas you will need an optional combiner
to connect to the TV.
75 Ω L AUDIO R
MONITOR OUT AV1 AV2 VIDEO S-VIDEO
U/V
Combiner
75-300 Ohm Adapter
Back of TV
