background image

! Bend the ear hook to

fit your ear

Warning

Don't pull the ear hook side way over
its limit, it will break the ear hook joint.

!

!

!

Low-battery indication

Battery recharging

Fully

The status light will flash red instead of green when the battery is low.

There will also be a short beep every few minutes. When the battery level is

too low ,

the Headset will automatically power off. It cannot be powered on

again unless the charger is connected or the battery is charged

.

for at least 5

minutes

To recharge the battery, connect the charger cable to the Headset.

During

recharging, the status light shows a steady red light if the headset is turned off
but the red light will dim once every 3 seconds while the headset is on.

A steady green status light indicates that the headset is off and is fully charged.
Green light dimming once every 3 seconds indicates that the headset is on and
fully charged.

charged indication

Green LED

dim once every 3 sec

Red LED

dim once every 3 sec

Turn

on

Turn

off

Headset under

charging

Headset

Fully charged

Green LED on

Red LED on

1. Put on the headset with the ear hook behind your ear.
2. Bend the ear hook gently to fit your ear.
3. Make sure the microphone is pointing towards your mouth.

Disclaimer

:

Talk time and stand by time of the VO

120

Headset will vary

depending on mobile phone model being used

-

Bluetooth

X

! How to wear

AC Adaptor

AC M

ains

! Charging Connection Diagrams

(1) A/C charging

NOTE
BQB

CE and FCC approved

:

,

.

A / C Adaptor

Accessories Table

Description

Federal Communication Commission Interference Statement

-

-

-

-

This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation.

This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications.

However, there is no

guarantee that interference will not occur in a particular installation.

If this

equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.

FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate this
equipment.

IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
minimum distance 20cm between the radiator & your body.
This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.

!

!

!

!

Charging the battery

Turning on the Headset

Turning off the Headset

Putting Headset in Pairing Mode

Thank you for buying new VOX 120

Headset. Before first time use, it

is important to charge the battery for 12 hours.

While the Headset is powered down, press and hold S1 for 2 seconds. A low
tone followed by a high tone will indicate that the Headset is powered up. The
status light will be green for 1 second. Afterward, the status light will flash
green every 3 seconds.

While the Headset is powered up, press and hold S1 for 5 seconds. A high tone
followed by a low tone will indicate that the Headset is powered down. And the
status light will be red until S1 is released.

Make sure the Headset is fully charged and charging cable disconnected from it
before pairing starts. While the Headset is powered off, press and hold S1 for 4
seconds. The status light will flash alternately green and red to indicate that the
Headset is in Pairing Mode.

Follow the operating instructions for your

mobile phone to start the

pairing process. Typically, this has to be done by going to a setup or connect
menu and then selecting the options to detect

devices.

may take several seconds to establish a connection.

Your phone s display should indicate

that it has found the

VOX 120

headset and ask if you want to pair it. You should confirm this. The phone s
display would prompt you for a passkey or PIN. Enter a sequence of

0000

and confirm

The Headset status light will flash green every 3 seconds, indicating successful
pairing. Probably the phone will also ask whether you want to change the
headset s name. We recommend you should approve the VOX 120 name and
not change it.

If pairing does not work as expected, turn the headset and phone off and wait
for 10 seconds. Turn the headset and phone on again and repeat all steps
from beginning.

Bluetooth

Bluetooth

Bluetooth

Bluetooth

'

'

.

'

1. On Off S1
2 Volume Up (S2)
3 Volume Down S3
4. Status Light
5. DC Socket
6 Speaker
7 Knuckle Joint
8 Microphone
9 Ear hook

/

(

)

.

.

(

)

.

.

.

.

!

!

!

!

!

!

Answering Incoming Calls

Transferring Calls

Muting the microphone

Ending Calls

To make a new call using voice dialing

Redialing last dialed number

When an incoming call is present, the Headset will ring .

Pressing S1 will

answer the call. The status light will flash fast while the call is in progress.
(once every second)

(For Nokia 3650 or equivalent models)

When you are in session, calls can be transferred from the

phone to

the Headset and from the Headset to the

phone.

To transfer a call from the

phone to the Headset: press S1 once, the

call will be transferred to the Headset.

To transfer a call from Headset to the

phone, please follow the

operating instructions of your phone.

Pressing both S2 and S3 buttons simultaneously for about a

second, the

microphone will be muted. A periodic beep tone will be heard while the mute
function is active.

When the microphone is muted, press on both S2 and S3 buttons
simultaneously will end the mute function and the periodic beep tone will stop.

While a call is in session on the Headset pressing S1 will disconnect the call.
After the call is disconnected, the status light will flash every 3 seconds

To reject a call (this function will only be supported by some mobile phones,
e.g. Nokia 3650 or Siemens S55)
When the Headset rings, press and hold S1 until you hear a long beep tone.

1.Make sure the voice dialing function is enabled in the mobile phone and the
mobile phone is within the range of the Headset. Press S1 on the Headset
shortly.
2.After you hear the beep tone in the Headset, make a voice dial as you
normally would by saying the name of the contact as set up in the memory of
the mobile phone. The call will be connected in a few seconds.

(this function will only be supported by some

mobile phones, e.g. Nokia 3650 or Siemens S55)

To redial the last dialed number, press and hold S3 for 2 seconds. short low
tones will indicate an attempt to redial.

Bluetooth

Bluetooth

Bluetooth

Bluetooth

To mute the microphone during an active call

To end the mute function

Requires a

mobile phone with Voice Dialing function

Bluetooth

! Right or left ear

If you want to wear the Headset on your right ear, you have to change the
orientation of the ear hook.

2) Put the ear hook back to the

knuckle joint and pull it down

firmly.

1) Pull the ear hook upward from

the knuckle joint and flip the

hook 180 degrees.

Right ear orientation

Left ear orientation

Bluetooth Headset

VOX 120

User Manual

! Adjusting Speaker Volume

.

.

,

.

While a call is in session, repeatedly pressing and releasing S2 will
increase the speaker volume and repeatedly pressing and releasing S3
will decrease the speaker volume on the Headset

There is a key tone to

indicate volume increase or decrease

However

a warning tone will be

heard when the volume level reaches its maximum or minimum

Health and safety

Do not allow the product to come into contact with liquid. Do not open it.

1. Philips Royal Electronics manufactures and sells many products targeted

at consumers, which, like any electronic apparatus, in general have the
ability to emit and receive electro magnetic signals.

2. One of Philips' leading Business Principles is to take all necessary health

and safety measures for our products, to comply with all applicable legal
requirements and to stay well within the EMF standards applicable at the
time of producing the products.

3. Philips is committed to develop, produce and market products that cause

no adverse health effects.

4. Philips confirms that if its products are handled properly for their intended

use, they are safe to use according to scientific evidence available today.

5. Philips plays an active role in the development of international EMF and

safety standards, enabling Philips to anticipate further developments in
standardization for early integration in its products.

The Declaration of conformity is available on www.p4c.philips.com.

On line help: www.p4c.philips.com

Electric, Magnetic and Electromagnetic Fields ("EMF")

Conformity

Maintenance and service
