Philips 19C2502E11 User Manual
En introduction, Feature highlights
1
E
N
Introduction
The PHILIPS 109S color monitor displays sharp and brilliant images of
text and graphics with a maximum resolution up to 1920x1440 pixels. It
is optimal for Windows, CAD / CAM / CAE, desktop publishing, spread
sheets, multi-media, and any other application which demands large
screen size and high resolutions.
This monitor automatically scans horizontal frequencies from 30KHz to
95KHz, and vertical frequencies from 50Hz to 160Hz. With
microprocessor based digital controlled circuit, the monitor can
automatically adjust itself to the video card’s scanning frequency and
displays an image with precise parameters you desire. The wide range
of scanning frequency supports variety of operating platforms, such as
IBM PC and compatibles, Apple’s Macintosh, Quadra and Centris
families, Power PC and workstations.
Feature Highlights
•
On-Screen-Display function provides more informations when the
user operates the control functions. This feature provides user-
friendliness and ease-of-use when operating the monitor.
•
Anti-Glare and Anti-Static screen coating eliminate any bad effects
caused by the screen surface such as reflection of the room lights
and dust attraction.
•
With Color Adjustment function you can easily choose different
preset color temperatures or set your own customized color
parameters.
•
Image Tilt Adjustment function provides correction of rotated image.
This correction can minimize the distortions caused by outside
environments, such as earth magnetic field.
• Green Design (option) including automatic power saving function
(NUTEK) and low emission MPRII compliance shows our commitment
in environmental care.
•
Plug and Play allows communication between the monitor and PC
system for optimal video configuration via DDC1/DDC2B of VESA
standard.
