Stand assembly, Attaching the base, Stand assembly 1 2 3 – Philips 46PFL3608-F7 User Manual

Page 65

Text mode
Original mode

Stand Assembly
1

× 4

Attaching the Base

You must attach the base to the Unit to have it as a table top Unit.
Be sure the front and rear of the base match the proper direction. For
large screen TVs, at least 2 people are required for these steps.

× 4

Note(s)

●

Make sure to use a table which can support the weight of this Unit and is larger than this
Unit.

●

Make sure the table is in a stable location.

●

When attaching the base, ensure that “FRONT” with an “arrow”, written on the bottom
of the base, is downward.

●

When attaching the base, ensure that All Screws are tightly fastened. If the base is not
properly attached, it could cause the Unit to fall, resulting in injuries as well as damage to
the Unit.

●

To remove the base from this Unit, unscrew the Phillips head screws by reversing the
procedure. Be careful not to drop the base when you remove it.

English
