4 EN
Overview of the speaker
a
• Power the speaker on or off.
• When the speaker is powered
off, press and hold to clear pairing
information.
b
• During a call, mute the integrated
microphone or release it from mute
status.
c
• Start, pause, or resume play.
• Press to answer an incoming call.
• Press to end the current call.
• Press and hold to reject an incoming
call.
• Press twice to dial the last called
number.
• Press twice to hold on the current call
and answer another incoming call.
a
b
d
c
e
h
g
f
d Bluetooth indicator
• Indicate the current Bluetooth
connection status.
e AUX
• Connect to an external player.
f DC 5V
• Recharge the built-in battery.
g Integrated microphone
h BATT
• During charging, indicate the current
battery status.
