120 volts ac 2 wire single phase, Page 17 – Bunn VP17B User Manual
Page 17
Page 17
10860 061501
SCHEMATIC WIRING DIAGRAM
VP17-1/-2/-3
10862.0003F 9/97 ©1997 BUNN-O-MATIC CORPORATION
P2
P1
FRONT WARMER
100W
WHI
WHI
P3
100W
WHI
BRN/BLK
VIO
WHI
REAR WARMER
WHI
WHI
100W
LOWER WARMER
N
WHI
120 VOLTS AC 2 WIRE
SINGLE PHASE
BLK
BRN/BLK
BLK
VIO
VP17-3 DUAL SIDE WARMER ASSY
1320W
BLK
TANK HEATER
L1
GRN
BLK
BLU
SW. & THERMOSTAT
ON/OFF SWITCH
WHI/RED
"KEEP WARM" HEATER
50W
WHI
BLK
LIMIT
THERMOSTAT
WHI
100W
REAR WARMER
WHI
WHI
P3
P1
VIO
BLK
VP17-2 TOP WARMER ASSY
VIO
WHI
ON/OFF SWITCH
ON/OFF SWITCH
ON/OFF SWITCH
