Replace drive belt

Use only BISSELL Style 10 Replacement Belts
(#32074) in your BISSELL PowerForce Bagless.

Unplug cleaner from electrical outlet.

With rotating floor brush removed from vacuum
cleaner (Steps 1-4 of Check rotating floor brush
and drive belt), grasp old drive belt and remove
from motor pulley. Discard old drive belt.

Place new drive belt over motor pulley and
stretch other end over rotating floor brush in
the space between the bristles.

Place ends of rotating floor brush down into
slots on sides as shown.

Turn rotating floor brush by hand several times
in direction of motor pulley. If properly installed,
drive belt will center itself on rotating brush.

Reposition brush cover and four screws. Make
sure end of brush cover is snapped into place.

Replace light bulb (select models)

Select models are equipped with a headlight.
Use only BISSELL Replacement Bulbs in your
BISSELL PowerForce Bagless.

Unplug cleaner from electrical outlet.

Using a flat screwdriver, table knife or coin,
insert into the slot on the right of the lens
and gently push inner latch to the left as
shown to remove the lens.

Determine the light bulb type of your vacuum:
Standard Bulb (#203-1297) – approximately 1”
long, flat end
Large Bulb (#203-1007) – approximately 2”
long, round end

Standard Bulb – remove the bulb from the
socket by grasping bulb and pulling straight
out. Install the new bulb by pushing it gently
into the socket until the bulb snaps into place.

Large Bulb - remove the bulb from the
socket by pushing bulb in gently and
turning it towards brush. Install the new bulb
by pushing it gently into the socket and
turning away from the brush.

Reposition lens, by inserting tab on left side
and then pushing the right side back into place.

aintenance and care

Brush

Cover

Press here

Large Bulb

Standard Bulb
