MVM MODIFICATION INSTRUCTIONS

••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••

MVM Instructions |

Page 2

Begin forming the Multi Vehicle Mount by cutting with a tin snips along

the solid red line. See picture #1 to the left. This will give you a ﬂ at sur-

face to work with. Smooth out with a ﬁ le if necessary. Note: You do not
want any sharp edges.

At this point, your mount should look like the image in picture

#2. Continue by placing the mount in a vise and bend along

the dotted line as shown in picture #2. Bend the bracket at a 90

degree angle so that it is ﬂ at along the backside. Note: It is easiest

to bend the bracket with a vise, then use a small hammer to ﬂ atten

to perfection.

After Step 6, your bracket should look like picture #3 below.

When it is bent at a near 90 degree angle, smooth out the edges

so there are no sharp points. Use a crackle coated paint if you

have damaged any exposed areas.

Return to

Step 3

on page 1

to continue your installation.

The Bracketron MVM-35-05 mount is a modiﬁ able mounting bracket. The illustrations on the left show how this mount should

look during and after the modiﬁ cation steps in order to ﬁ t the listed vehicles on the front page of this manual.

Many vehicle

applications may not require any modiﬁ cations to the mount. If this is the case it will be noted below and there will be no steps

to follow on this page.

PLEASE NOTE
