Specifications

* Both channels driven at nominal line voltage 120V AC, 60 Hz.

** The X600 requires a 20A, 125V AC power receptacle because its maximum current requirements

exceed the capacity of a typical 15A receptacle. The receptacle is a NEMA 5-20R style (right).

11

X600

X450

X300

Power Output*

600W / Ch @ 70V

450W / Ch @ 70V

300W / Ch @ 70V

Input Sensitivity (selectable)

1V/0.1V

S/N Ratio (20 kHz BW)

104 dB ref. 70V, F.P.

Class of Operation

H

Connector: Power

Input

Output

20A line cord**

15A line cord

15A line cord

Pluggable 3-pin terminal strips

5-pin "touch-proof" Barrier Strip

Power Bandwidth

20 Hz to 40 kHz, < 0.5% THD

THD @ 1 kHz Rated Power

less than .02%

Rated Load Impedance (per Ch.)

8 ohms

11 ohms

16 ohms

Frequency Response @ 1 watt

20 Hz to 20 kHz ± 0.25 dB

Output Regulation

1.5 dB @ 70V

Inputs

100k-ohm electronically balanced, 3-pin pluggable terminal strip

Low-Cut Filter

60 Hz, 2nd order roll-off, switch defeatable per channel

AC Input Voltage Range

95-130V AC, 60 Hz

AC Current Rating (full power)**

20A**

15A

12A

AC Voltage

120V AC, 60 Hz

Indicators

Status, Limit, Signal, AC Power Status (Rear)

Temperature Range

15° to 105° F

Thermal Emissions (Full Power)

Cooling

Dual Forced Air Variable Speed Fan

Physical Dimensions (W x H x D)

17" W x 3-1/2" H x 18-1/4" D

Product Weight

46 lb.

44 lb.

41 lb.

Protection

RF, DC, Low frequency, Thermal, Low impedance, Circuit Breaker, Short Circuit, Clip Limiting

Special Features

Sequential Turn-On Circuitry (defeatable), Sleep Mode (defeatable),

Back-Slope™ AC Voltage regulation, Toroidal Power Transformer, Input Sens, CH B Input Select

Approvals

1667 BTU/Hr

1537 BTU/Hr

1195 BTU/Hr

W

G

Listed to UL Standard 60065 for U.S. and Canada
