ASSEMBLY INSTRUCTIONS
READ ALL SAFETY WARNINGS & ASSEMBLY INSTRUCTIONS CAREFULLY
BEFORE ASSEMBLING OR OPERATING YOUR GRILL.
WE RECOMMEND TWO PEOPLE WORK TOGETHER WHEN ASSEMBLING THIS UNIT.
The following provided tool is required to assemble this Brinkmann Professional Dual Zone
Charcoal/Gas Grill:
• Phillips Head Screwdriver
24
PARTS LIST:
2 Heat Distribution Plates
1 Back Panel
1 Right Panel Assembly
1 Cart Base
1 Left Panel Assembly
1 Magnetic Door Stop
2 Front Doors
1 Tank Holder
2 Door Handles
4 Door Handle Supports
2 Air Vent Dampers
1 Tank Block Bar
4 Locking Casters
1 Cooking Chamber Divider
2 Control Knobs
1 Grill Body Assembly
1 Left Side Table
1 Left Side Drawer
1 Left Side Drawer Handle
1 Right Table
1 Right Side Towel Rack
1 Handle
1 Crank
2 Charcoal Ash Trays
2 Handle Supports
1 Handle Bar
1 Door Bracket
2 Cooking Grills
