ScyTek Electronics ASTRA 300RS - Manual (Page 4)

Page 4 - Astra 300RS
Adding/Replacing One-Way Transmitters
To replace lost or stolen transmitters or to add additional transmitters into the system, have all desired
transmitters ready and follow the steps below.
Note: Up to 4 transmitters can be programmed to operate the system. To erase any previously stored
transmitter codes, be sure to program all 4 transmitter memory locations.
To program the transmitter(s):
1. Turn on the ignition key On, Off, On, Off, and back On.
· The Horn will flash 3 times.
2. Press and hold the Valet switch for 5 seconds.
· The Horn will flash 5 times.
· The LED will illuminate.
3. Press Button 1 on the first transmitter.
· The horn will flash once.
4. Repeat steps 3 for each transmitter (up to 4).
5. Turn off the ignition key.
Battery Replacement
Your Remote Transmitter uses a 12 volt alkaline battery (type 23A), which will require replacement in
time. Depending on the amount of use, the battery may last up to six months or more before it
needs replacement.
When the battery needs replacing, the system’s operating range will decrease or the transmitter LED
may not be as bright.
In order to change the battery, first remove 2 screws from the back of the transmitter and separate
the top and bottom halves of the case.
While replacing the battery make sure that the positive and negative terminals are positioned cor-
rectly, then carefully reassemble the transmitter case.
Panic Mode
In the event of an emergency the transmitter’s remote Panic feature can be used to instantly trigger
the Horn.
To activate the Panic Mode:
1. Press and hold Button 1 for 3 seconds.
· The horn will sound.
· The parking lights will flash.
· The doors will unlock* allowing access to the vehicle.
2. Press Button 2 to stop Panic Mode.
* If the ignition is on when the Panic feature is activated, the doors will lock for personal safety.
If not deactivated using Button 2, the Panic Mode will automatically exit after 30 seconds and the system
will be restored to its previous Lock/Unlock state.
System Operation 300RS
