2.36 TTL LCD Connector (CN25)
Pin Signal Pin Signal
1 LCD Volt. 2 LCD Volt.
3 Ground 4 Ground
5 LCD Volt. 6 LCD Volt.
7 Back-light Enable 8 Ground
9 B0 10 B1
11 B2 12 B3
13 B4 14 B5
15 B6 16 B7
17 G0 18 G1
19 G2 20 G3
21 G4 22 G5
23 G6 24 G7
25 R0 26 R1
27 R2 28 R3
29 R4 30 R5
31 R6 32 R7
33 Ground 34 Ground
35 LCD_CLK 36 VSYNC
37 TTL_DE 38 HSYNC
39 N/C 40 N/C
