Server Properties Configuration
34 Chapter 5 Manual Documentation Number: ESR90x-0508m
B&B Electronics Mfg Co Inc – 707 Dayton Rd - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com
B&B Electronics Ltd – Westlink Commercial Park – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445 – www.bb-europe.com
Netmask
The default LAN netmask is configured for a Class C address. The user may
change this. Default is 255.255.255.0
Gateway
The Gateway IP address allows users to access the Serial Server from outside
the LAN.
MAC Address
The MAC address is fixed and cannot be changed. It is assigned in the
factory. Every Ethernet device manufactured has it own unique MAC
address.
Version & Date
The currently loaded version of the firmware, and when it was released, is
shown here.
Link Status
Link status automatically displays the type of Ethernet connection. It will
either display 10BaseT or 100BaseTX in full duplex or half duplex. This will
depend on the LAN, switches, hubs used in the LAN topology.
Server Serial Port
This field indicates the number of the port for with Serial Server properties
are currently being displayed. Changing the number in this field will cause
all the other fields to display the properties for the specified port. Note,
however, that before changing ports, any changes to properties must be
Updated
(Saved) or the
n
will not retain them.
Baud Rate
The serial port baud rate on the Serial Server must match the serial baud rate
of the connected device unless using Virtual COM Mode. In Virtual COM
Mode the software program will establish serial settings.
Data/Parity/Stop
Set this to match the data format used by the serial device connected when
Virtual COM Mode is not being used.
