Brinkmann Pro Series 6418 - Manual (Page 22)

ASSEMBLY INSTRUCTIONS
READ ALL SAFETY WARNINGS & ASSEMBLY INSTRUCTIONS CAREFULLY
BEFORE ASSEMBLING OR OPERATING YOUR GRILL.
21
1 Side Table
1 Door Bracket
1 Electronic Igniter Button
1 Electronic Igniter Spring
1 Side Burner Assembly
1 Side Burner Knob
1 Left Side Cart Panel
1 Right Side Cart Panel
1 Rear Cart Panel
4 Locking Casters
1 Bottom Cart Shelf
2 Doors
1 Small Basket
1 Large Basket
PARTS LIST:
1 Hood
1 Hood Handle
1 Warming Rack
4 Cooking Grills
4 Heat Distribution Plates
4 Grill Burners
1 Grease Tray
1 Grill Body Assembly
1 Grease Cup
1 Grease Cup Bracket
1 Side Burner Grate
4 Control Knobs
1 Temperature Gauge
1 Brass Burner Ring
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
21
22
23
24
25
26
WE RECOMMEND TWO PEOPLE WORK TOGETHER WHEN ASSEMBLING THIS UNIT.
The following provided tools are required to assemble this Brinkmann Pro Series 6418 Grill:
• Flathead Screwdriver (included)
• Hex Nut Wrench (included)
20
27
28
