PQ-6 PLUS (RO)
24
S
WITCH
D
EFINITION
T
ABLES
Table 4-1. Option Switch SW1 Baud Rate Selection (0=OFF, 1=ON).
Switch Bank 1
Baud Rate
5
6
7
8
OFF
OFF
OFF
OFF
50
OFF
OFF
OFF
ON
75
OFF
OFF
ON
OFF
110
OFF
OFF
ON
ON
134.5
OFF
ON
OFF
OFF
150
OFF
ON
OFF
ON
300
OFF
ON
ON
OFF
600
OFF
ON
ON
ON
1200
ON
OFF
OFF
OFF
1800
ON
OFF
OFF
ON
2000
ON
OFF
ON
OFF
2400
ON
OFF
ON
ON
3600
ON
ON
OFF
OFF
4800
ON
ON
OFF
ON
7200
ON
ON
ON
OFF
9600
ON
ON
ON
ON
19200
Option Select
1 (OPT4)
ON=Buffer print mode.
2 (OPT3)
ON=Serial
OFF=Parallel
3 (OPT2)
ON=Enable Command Passthrough
OFF=Disable Command Passthrough
4 (OPT1)
OFF=Use FF (Form Feed) character for page eject.
ON=Use Multiple Line Feed for page eject.
Table 4-2. Option Switch SW2.
Switch Bank 2 Position
Function
1, 2
Printer type select (00=5256, 01=5224, 10=5225, 11=illegal)
3
Parallel Print option (OFF=PQ-6 responds to the busy and acknowledge
signals from the printer. ON=PQ-6 responds to the busy signal only. This
setting increases the data transfer rate to the printer.)
4
Configuration option (ON=DIP switch, OFF=Front panel)
5
Self-Test
6, 7, 8
Address select (0-6) 0=OFF, 1=ON
When the auto-feed jumper is installed in the ground position, the paper is automatically fed one line after
printing. This signal does not apply to all printers.
Jumper (J1) applies either +5 or ground or pin 14 of the Centronics printer connector.
