76 Instruction 3015-4275
Sensor Data Register Register 0x0016h R 82 bytes
Variable Type Length Description
Pressure Float 4 Manifold Pressure is PSIA
P_Volts Float 4 Pressure sensor output Voltage
Vacuum_P Float 4 Pressure with all value closed and pump on in PSIA
Ambient_P Float 4 Absolute Ambient Pressure in PSIA
Box_T Float 4 Enclosure Temperature in Degrees C
Box_T_Volts Float 4 Box temp sensor output voltage
Bench_T Float 4 Optical bench temperature in Degrees C
Bench_T_Volts Float 4 Bench temp sensor output voltage
Bench_Z_T Float 4 Optical bench temp in degrees C at last zero interval
Box_Z_T Float 4 Box temp in degrees C at last zeroing
PkPk_int UI 2 Current peak to peak A/D counts from detector
PkPk Float 4 Current peak to peak voltage from detector
Ave_PkPk Float 4 Running average voltage from detector
Zero_PkPk Float 4 Voltage measured at last zeroing
Noise Float 4 Largest Change in running average
AU Float 4 Current absorbance value
Ave_AU Float 4 Running Average of absorbance level
Bench_PPM Float 4 PPM in bench based on zone gas selection (uncorrected
for pressure and temperature)
STP_PPM Float 4 PPM corrected to STP (1 atm, 25 deg C)
Bench_UML Float 4 Micromoles/liter in bench (uncorrected0
Ambient_UML Float 4 Micromoles/liter corrected to ambient pressure
