Vehicle (with Seat)

• If you experience a problem with this product, or are missing a part, please call us at 1-800-348-0751, rather than return this product to

the store.

• Please identify all parts before assembly and save all packaging material until assembly is complete to ensure that no parts are discarded.

• Some parts were placed under the seat for shipment. Turn the lock fastener 1/4 turn and lift to remove the seat.

• Metal parts have been coated with a lubricant to protect them during shipment. Wipe all metal parts with a paper towel to remove any

excess lubricant.

6 Volt (4.0 Amp/Hr.) Charger

Handlebar Assembly

Front Wheels Assembly

Not Shown: Label Sheet

6 Volt (4.0 Amp/Hr.) Battery
