Operation
39
Pro-Picture menu
Some picture adjustments are available only when certain input sources are in use.
Unavailable adjustments are not shown on the screen.
FUNCTION
(default
setting / value)
DESCRIPTION
Keystone (0)
Corrects any keystoning of the image. Refer to
for more information.
Auto Resize
(on)
Automatically resizes the input signal pixel resolution to the native resolution
of the projector.
On: The pixel resolution of the input signal is converted to the native
resolution of the projector (800 x 600). For input signals with lower
resolutions, gaps in the pixels are automatically interpolated into the image
before being projected. This may distort the image clarity.
Off: The image is projected as its original resolution, with no pixel conversion.
For input signals with lower resolutions, the projected image will display
smaller than if resized to full screen. You could adjust the zoom setting or move
the projector towards the screen to increase the image size if necessary. You
may also need to refocus the projector after making these adjustments.
Aspect Ratio
(Native)
There are three options to set the image's aspect ratio depending on your input
signal source.
See
"Selecting the aspect ratio" on page 28
for details.
H Position
(0)
Adjusts the horizontal position
of the projected image.
V Position
(0)
Adjusts the vertical position of
the projected image.
Phase
(depends on
the selected
input
source)
This function allows you to adjust the clock phase
to reduce image distortion.
H Size (0)
Adjusts the horizontal width of the image.
-30
+30
-30
+30
