Exploded Views and Parts Lists
Item Part # Description
1 B192658GS CRADLE (Includes Items 20, 31,
76 & 77)
2 194150GS KIT, Mount, Vibration, 45°
3 67989GS NUT, M8 Flange Serrated
4 190220GS HOUSING, Engine Adapter
5 * NUT, Hex M8 - 1.25
6 NSP ASSY, Alternator (see page 5)
7 * TPHMS, M8 - 1.25 x 35
8 96796GS WASHER, M8 Flat
9 * WASHER, Lock 5/16 M8
10 190274DGS SCREW, 3/8-16 x 7/8
11 53122GS HHCS, 5/16-24 x 6-1/2
12 * HHCS, M8 1.25 x 25
13 * WASHER, 5/16 Flat
14 193021GS BRACKET, Muffler
15 710082 GASKET, Exhaust
16 * HHCS, M6 - 1.0 x 12
17 192898GS MUFFLER
18 710090 NUT
19 83083GS SCREEN, Spark Arrest
20 B4986GS DECAL, Ground
21 194153GS KIT, Vibration Mount
22 86494GS SCREW, Wing M6 1.0 x 16
23 86292GS SCREW, 10-16 x 3/4, Self Drill
24 J193053GS SHIELD, Heat
25 191190GS CAP
26 74908GS TAPTITE, M5-0.8 x 10
31 200310GS DECAL, Warning Exhaust
34 195422GS COVER, RBC, Plastic with Cap
35 791745 KIT, Fuel Hose (cut to fit)
36 * WASHER, M6 - 1/4 Int. Shakeproof
Item Part # Description
37 B2153GS SCREW, #10 Self Drilling
38 192376GS SCREW, 12-24 x 1/2 THD Forming
40 194212GS KIT, Fuel Tank Hardware (Includes Qty
of 4)
41 193272GS VALVE, Tank
44 195988GS ASSY., Tank, Fuel 4.5-Gallon (Includes
Items 41, 50, 51, 52, 53 & 55)
45 189135GS CAP, Fuel, Vented
48 195373GS WIRE, Ground
50 202997GS DECAL, CO Warning
51 194984GS DECAL, Danger
52 94480GS DECAL, Start Instructions
53 189136GS GAUGE, Fuel
55 197797GS DECAL, Fuel Shutoff
58 195512GS ASSY, Control Panel
76 195459GS DECAL, Neutral Ground
77 195940GS DECAL, Ground French
99 189759GS KIT, Fuel Repair Valve
900 § ENGINE
Parts Not Illustrated
43483GS PLUG, 250V 20A, 4 Prong
100523GS PLUG, 125V 30A, 3 Prong
65787GS CABLE, Battery Charge
BB3061GS OIL BOTTLE
203336GS MANUAL, Operator’s
203589GS KIT, Decals Service
* - Items without part numbers are common fasteners and
are available at your local hardware store.
§ - Contact Engine Manufacturer
PARTS LIST - MAIN UNIT
