Page 56: Ystems, Fig. 6.6.1)
242 Islander
®
6.6
s
eCtIon
6 • e
leCtrICal
s
ysteMs
R
Speed changes you.
TM.
I
gnItIon
s
wItCh
(FIg. 6.6.1)
TO EngInE
RUn CIRCUIT
16 aWg
PURPlE/BlaCk
16 aWg
PURPlE/BlaCk
lanyaRD
sTOP sWITCh
B
EXhaUsT
12 aWg RED
TOEXhaUsT
BREakER
fROM IgnITIOn
sWITCh ( I)
16 aWg
PURPlE/BlaCk
TO EngInE
B
RUn
Off
I
B
s
sTaRT
16 aWg
yEl/RED
TO sTaRTER
sOlEnOID
shIfTER's nEUTRal
safETy sWITCh
20a
12 VOlT DC
fROM EngInE
12 aWg
RED/BlaCk
a
note: This drawing contains information proprietary to Baja
Marine Corp. any unauthorized disclosure, use, or reproduction is
expressly prohibited, unless written permission of Baja
