242 Islander ® 2.2
s
eCtIon
2 • g
eneral
B
oat
a
rrangeMent
3. b
asic
b
oaT
D
iMensions anD
c
learances
(u
niTeD
s
TaTes
s
TanDarD
s.a.e.)
242 I
slander
s
pecificaTions
Overall length .................................................................24'2"
Overall length (w/ drive down)........................................24'8"
Overall length w/ swim Platform .................................25'9½"
Beam (width) .....................................................................8'6"
Draft (stern drive down) ..................................................... 38"
Draft (stern drive up in trailering position)...........................24"
Dry Weight .........................................................4,400 pounds
fuel Capacity......................................................... 102 gallons
h
eiGhT
D
iMensions
from keel
without Windscreen.............................................................64"
keel To Top
Of Windscreen.................................................................... 77"
from Waterline
without Windscreen.............................................................44"
from Waterline to
Top of Windscreen..............................................................57"
(fIg. 2.2.3)
Boat Dimensions and Clearances
(Fig. 2.2.1)
24'2"
24'8"
64"
77"
Specification measurements are approximate
and subject to variance.
Stern Drive (Inboard-Outboard) Engine
(Fig 2.2.2)
sTERn DRIVE UnIT
(lOWER UnIT)
DRafT
(stern Drive Down)
38"/96.52cm
WaTER lInE
hUll
(TRansOM)
EngInE
8’ 6”
Beam
25'9½"
