Brinkmann 4210 User Manual
Page 24

23
Choose a good, cleared assembly
area and get a friend to help you put
your grill together. Lay cardboard
down to protect grill finish and
assembly area.
CAUTION! Some parts may
contain sharp edges.
Wear protective gloves
if necessary.
Step 1
Attach locking casters to the bottom
of the left legs. Tighten caster bolts
securely using hex nut wrench
provided in parts pack.
Step 2
Install the wheels as illustrated, by
inserting the wheel axle bolts
through the wheels, right side leg
axle holes. Insert hitch pin through
axle bolt to lock in position.
Step 3
Attach cart base to left legs. Insert
four M6 X 12mm bolts through cart
base and into legs and tighten
securely.
Locking Caster
Hex Nut Wrench
Hitch Pins
Axle Bolts
