Baja Marine Performance H2X - Manual (Page 32)

H2X ® 2.4
S
eCtion
2 • g
eneral
B
oat
a
rrangeMent
6. G
eneral
D
eck
l
aYouT
GENERAL DECK LAYOUT
(FIG. 2.4.1) fWD
REaR
(afT)
lEfT
(PORT)
RIgHT
(sTBD)
Navigation Light
(Bow)
Deck Hatch
Gauges
Helm Seat
Passenger Seat
Inspection Plate
Aft Bench Seat
Engine Hatch
Cleat Cleat
Navigation / Anchor Lt.
(Stern)
Cleat
fuel Tank Opening
fuel fill Cap
Ladder
Cleat
Steering Wheel
