H2X
®
2.2
S
eCtion
2 • g
eneral
B
oat
a
rrangeMent
3. b
asic
b
oaT
D
iMensions
anD
c
learances
(u
niTeD
s
TaTes
s
TanDarD
s.a.e.)
H2X s
pecificaTions
Overall length ................................................................24'½"
Overall length (w/ drive down)........................................24'11"
Beam (width) .....................................................................8'4"
Draft (stern drive down) ..................................................... 35"
Draft (stern drive up in trailering position)...........................20"
Dry Weight .........................................................3,900 pounds
fuel Capacity.......................................................... 80 gallons
h
eiGhT
D
iMensions
from keel
without Windshield.............................................................57 ½"
keel To Top
Of Windshield.....................................................................60"
from Waterline
without Windshield..............................................................37 ½"
from Waterline to
Top of Windshield................................................................40"
B
oat
d
iMenSionS
and
C
learanCeS
(F
ig
. 2.2.1)
Specification measurements are approximate
and subject to variance.
S
tern
d
rive
(i
nBoard
-o
utBoard
) e
ngine
(F
ig
2.2.2)
sTERn DRIVE UnIT
(lOWER UnIT)
DRafT
(stern Drive Down)
35"/89cm
WaTER lInE
HUll
(TRansOM)
EngInE
24'½"
57 ½"
60"
8’ 4”
Beam
(fIg. 2.2.3)
