REF. PART REF. PART REF. PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION
31M700
K Included in Engine Gasket Set−Ref. No.358.
D Included in Carburetor Overhaul Kit−Ref. No. 121 or 121A.
z
Included in Carburetor Gasket Set−Ref. No. 977.
∆ Included in Valve Gasket Set−Ref. No 1095.
Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.
5643−10 Assemblies include all parts shown in frames. 03/13/2007
10
501 691188 Regulator
Used on Type No(s).
0101, 0112, 0237.
−−−−−− Note −−−−−−
691185 Regulator
Used on Type No(s).
0111, 0167.
503 691532 Strap−Starter
505 691251 Nut
(Governor Control
Lever)
510 693699 Drive−Starter
513 692024 Clutch−Drive
521 690581 Shield−Cable
523 699908 Dipstick
524 K691032 Seal−Dipstick Tube
525 697184 Tube−Dipstick
Used on Type No(s).
0101, 0112, 0215,
0234, 0237.
−−−−−− Note −−−−−−
697085 Tube−Dipstick
Used on Type No(s).
0111, 0167.
526 697088 Screw
(Regulator)
Used on Type No(s).
0101, 0112, 0237.
−−−−−− Note −−−−−−
697348 Screw
(Regulator)
Used on Type No(s).
0111, 0167.
527 698467 Clamp−Tube
544 692034 Armature−Starter
552 697144 Bushing−Governor
Crank
559 697561 Screw
(Remote Choke Stop)
Used on Type No(s).
0111, 0237.
−−−−−− Note −−−−−−
693675 Screw
(Remote Choke Stop)
Used on Type No(s).
0112.
562 691119 Bolt
(Governor Control
Lever)
578 692306 Wire Assembly
579 691029 Nut
(Starter Cable)
584 697112 Cover−Breather
Passage
601 791850 Clamp−Hose
613 691416 Screw
(Muffler)
613A 690297 Screw
(Muffler)
613B 691678 Screw
(Muffler)
614 691620 Pin−Cotter
616 692012 Crank−Governor
617 KD692138 Seal−O Ring
(Intake Manifold)
634 D690802 Spring/Seal Assembly
634B D698779 Spring/Seal Assembly
635 691909 Boot−Spark Plug
643 698401 Retainer−Air Filter
654 690958 Nut
(Carburetor)
668A 691500 Spacer
(Rotating Screen)
676 397630 Deflector−Muffler
Used on Type No(s).
0112.
677 690661 Screw
(Muffler Deflector)
Used on Type No(s).
0112.
691 K692407 Seal−Governor Shaft
692 690572 Spring−Detent
697 690372 Screw
(Drive Cap)
718 690959 Pin−Locating
729 691335 Clip−Wire
(Wire Saddle)
729A 691224 Clip−Wire
(Aluminum Coated
Steel)
741 697128 Gear−Timing
750 790832 Screw
(Oil Pump Cover)
757 697607 Link−Counterweight
758 697134 Counterweight
759 697392 Pin−Counterweight
783 693713 Gear−Pinion
789 692037 Harness−Wiring
Used on Type No(s).
0101, 0111, 0112,
0167.
789A 698329 Harness−Wiring
Used on Type No(s).
0215, 0234, 0237.
797 693167 Nut
(Brush Retainer)
801 691283 Cap−Drive
802 691286 Cap−End
803 Housing−Starter
(Not Serviced
Separately, Order
Starter Motor 693551)
823 698941 Screw
(Muffler Adapter)
Used on Type No(s).
0111, 0112.
830 691095 Stud−Rocker Arm
832 790244 Guard−Muffler
Used on Type No(s).
0112.
836 691676 Screw
(Muffler Guard)
836A 690367 Screw
(Muffler Guard)
842 K691031 Seal−O Ring
(Dipstick Tube)
847 790442 Dipstick/Tube
Assembly
Used on Type No(s).
0101, 0215, 0234,
0237.
−−−−−− Note −−−−−−
790443 Dipstick/Tube
Assembly
Used on Type No(s).
0111, 0112, 0167.
851 692424 Terminal−Spark Plug
864 697346 Adapter−Muffler
Used on Type No(s).
0111, 0112.
868 K∆690968 Seal−Valve
877 393456 Wire/Connector−Altern
ator
(Dual Circuit)
877B 393537 Wire/Connector−Altern
ator
(Tri Circuit)
877C 399916 Wire/Connector−Altern
ator
(10 Amp Circuit)
