4
IT
Installazione dell’hardware
4
3. Individuare gli slot PCI sul circuito stampato del computer. Individuare uno
slot PCI libero. Rimuovere la lastra di metallo che ricopre lo slot sul retro
corrispondente allo slot PCI Express selezionato. Utilizzare un cacciavite a
croce per rimuovere le viti. Fare riferimento alle immagini sotto illustrate.
staffa
posteriore
Slot PCI
